The fastener is intended for mounting a grating (welded or pressed) by fixing the upper clamping bracket with a self-tapping screw directly to the support (channel, I-beam, angle).

Durability of fasteners is ensured by the corrosion resistance of the coating (hot or thermal diffusion galvanizing).

The effectiveness of this kit is ensured with a support wall thickness of up to 6 mm, otherwise it is recommended to pre-drill the attachment point.

Staple size: according to the size of the cell step

Self-tapping screw size: 6,3х51; 6,3х60; 6,3х70.

This set of fasteners is used in cases where drilling of the supporting elements is not allowed, or the deck sections must be removable. For use in aggressive environments, fasteners are made of stainless steel.

Dimensions: staple and clamping bar - according to the size of the cell pitch, M8x70 bolt, M8 square nut.
